Description
Sensor
- High performance accelerometer
- 18 µg accelerometer bias instability
- ±16 g range
- High performance Gyroscope
- 1000°/s range
- 1.5°/hr gyroscope bias instability
- Attitude accuracy ±0.25°
- Fully calibrated and temperature compensated from –40°C to +85°C
Operation
- SAE J1939 communication protocol
- Adjustable sampling rates up to 500Hz (100Hz default)
- Triple power flexibility:
- 5V regulated
- 12V unregulated vehicle bus
- 24V unregulated vehicle bus
- Single CAN command adjusts for any mounting orientation
- Fully compliant to strict automotive and off-highway test standards
Package
- Reinforced PBT Thermoplastic, Hermetically sealed
- Steel compression limiters for additional ruggedization
- Ingress protection IP68, IP69K
- Highly compact and low profile
- 78.9 mm x 55.0 mm x 23.5 mm
- 107 grams
- RoHS, REACH, CE, UKCA certifications
