Description
Sensor
- Tactical grade gyro (1.5°/hr bias instability)
- Fully calibrated over entire temperature range
- Roll/pitch accuracy
- Static: 0.25°
- Dynamic: 0.5°
Operation
- Onboard Extended Kalman Filter for attitude estimation
- User-selectable accelerometer and gyroscope range
- Adjustable sampling rates up to 1 KHz
- Factory supported ROS1 and ROS2 driver
- SensorConnect software for configuration, control, display, and logging
- MSCL open source API for easy integration
Package
- Ruggedized IP68 package
- Precision-machined anodized aluminum enclosure
- Precision alignment features
- Compact and low profile
- 36.2 mm x 36.6 mm x 10.2 mm
- 17.7 grams
- –40 to +85°C operating temperature range
