Description
Sensor
- High Performance Accelerometer
- 100 µg/√Hz (8g standard)
- 2g, 4g, 20g, 40g options
- Super-stable Gyro
- 8 dph in-run bias (-40 to +85°C)
- Offset temperature hysteresis 0.05°/s
- ARW 0.3 °/√hr
Operation
- Adjustable sampling rates up to 1000Hz
- Forward compatible MIP Protocol optimizes bandwidth
- Configurable IMU outputs
- SensorConnect software for configuration, control, display, and logging
Package
- CNC Anodized Aluminum
- Precision alignment features
- Highly compact and low profile
- 38.0 mm x 24.0 mm x 9.7 mm
- 11.0 grams
- TTL UART interface (up to 921600 BAUD)
- –40 to +85 °C operating temperature range
